Description
Low Carbon wire-Hot Dipped Galvanized- COIL
Hot dip galvanizing means the immersion of Low carbon wire in a molten zinc tank at a temperature of 450 ° C which causes the steel to be covered with a thin and resistant layer of zinc
UNI EN10244-2:2003 EN10257-1 Tab 1 EN10257 Tab 2
Example Table :
| DIA. mm. |
TS N/mm2 |
TO. | Q.Zinc Gr/m2 mm. |
EL. % |
|---|---|---|---|---|
| 0.80 | 330-430 | +-0.015 | 28-35 min | >15% |
| 1.00-1.20 | 330-430 | +-0.015 | 28-35 min | >15% |
| 1.25-8.00 | 330-430 | +-0.020 | 28-35 min | >15% |
